thEQorange

Linear Phase Without Compromise

thEQorange

thEQorange

When purity is paramount.
A linear phase EQ with unparalleled clarity. For mastering ears, and other discerning engineers.

• Perpetual License: $990
• Subscription: $9.92 per month billed annually
($119 Annual Renewal)

thEQorange

A Dream Come True

Many mastering engineers, including MAAT founder Friedemann Tischmeyer, were fans of Algorithmix’s legendary original Linear Phase PEQ Orange. Unfortunately, the Algorithmix EQs were available only as 32 bit VSTs for PC and our workstations and our industry has evolved since then. Tischmeyer’s students repeatedly asked for alternatives, which caused him to scan the market for other high class EQs. Colleague Bob Katz recommended EQuilibrium, an insanely versatile tool, which Tischmeyer used for teaching. However, he could not find a satisfying alternative which would take the place of his original PEQ Orange.

The idea was born to reissue this masterpiece and make it available as 64 bit in all common formats and for macOS. An agreement with Algorithmix was made, and MAAT started up in mid–2017. Algorithmix fans heard of that and reached out to us, saying “…just redo it as it is; no extras, no nothing. We just want to have it back in 64 bit and for Mac.” That was encouraging. As a power user, Tischmeyer had some other ideas in mind regarding the UI. He wanted to make it more flexible and faster to use because there is no other tool in the mastering chain an engineer spends so much setup time with. The result? “I think we have achieved that. The UI allows super fast setup and has a number of unique features which help to do so: The positive & negative Contribution function including absolute difference, the adjustable sonogram which makes detecting energy spots you want to clean up easy, and the possibility to play a note on the piano you have in your head and just push the respective frequency to the active band section with one right click are just a few of the new features. What I like too is that I have an overview of all Sections as opposed to just one Section at a time.” In order to not end up with a strange Section order when using many filters, we also added the SORT button so you always have your Sections in ascending order.

Unobtrusive Power

thEQorange’s powerful features hide behind its clean and simple UI. Eye candy is great for newbies, but thEQo isn’t your typical filter: thEQorange packs all the advanced features you need into one resizable window that’s easy on the eyes. Not only does the UI “get out of the way” so you can be more productive, we’ve incorporated industry–first features that speed your workflow, neatly packaged to make thEQorange easy and intuitive to use.

Subtle Functionality

We’ve brought pristine fidelity and innovative user interface design to what used to be an unremarkable product category. With four monitoring modes, an ergonomic and uncluttered interface, intelligent monitor auto–gain plus crazy good sound, you’ve got to try thEQorange for yourself.

thEQorange
thEQorange

Better By Design

Whether you’re looking for surgically precise repair, colorless correction, or simply baggage–free spectral contouring, our proprietary, precision algorithm delivers on the promise of linear phase correction. Bring the power and purity of thEQorange to bear for all your surgical equalizing tasks.

thEQorange sounds more natural, organic and open. Listen for the difference, it just sounds correct.

Details

  • Exclusive Contribution Control™; positive addition only, negative addition only, EQ contribution only, and “normal” EQ out helps to aurally keep track of your progress
  • Proprietary algorithms result in extremely low noise and vanishingly small nonlinear distortion
  • Unique EQ design results in no perceptible unwanted coloration with mixes (processing artifacts well below -100 dBFS) — work with clarity, transparency, and definition
  • Equal delay at all frequencies regardless of filter settings, perfectly preserving the time relationship of harmonics in the original signal
  • Operates at up to 384 kHz sampling rate, suitable for high resolution audio (HRA), DSD or DXD production and post
  • Extended resonant or center frequencies up to 174.14 kHz, for processing in ultrasonic and near ultrasonic for all HRA production and post
  • 12 sections with 5 freely assignable parametric filter types; bell, low shelf, high shelf, low cut, and high cut
  • 5 freely assignable Panorama modes; stereo, mono (sum), L-R (difference), left–only and right–only
  • 80 bit double precision internals virtually eliminate rounding errors
  • Adjustable Q for bell and high/low pass filters make musical adjustments easy
  • Adjustable slope for shelving filters improve precision in the pass and stopbands
  • Double the stopband attenuation (ripple) compared to other filter implementations
  • Additional low and high pass filters can be overlapped to achieve steep “brickwall” slopes
  • Special oversampling for reduced aliasing when working with baseband (44.1 & 48 kHz) sample rates
  • No coloration or amplitude bumps even at very low frequencies
  • Optional inbuilt tone generator makes for quick location of trouble spots
  • SORT function organizes active Sections in ascending order
  • TUNE function aligns center frequencies to Western tunings
  • Sections have Solo and FLIP to quickly find and address trouble spots
  • Grid snap toggles between surgical and musical applications, emulating popular hardware resonant frequency choices, including Maselec and Manley
  • True Peak metering to avoid overs
  • AutoGain for effortless A/B comparisons
  • Resizable frequency response display for easy, high precision adjustments

Extras

  • Exclusive dual view, monochrome/color real time spectrogram with user adjustable temporal wiper lets you choose “when” to transition to low clutter monochrome
  • Choice of parametric editing via numerical fields or directly on the graphical display
  • Complete setup exchange across multiple instances
thEQorange is a highly specialized tool for mastering engineers who have access to diverse high end EQs for different tasks. There are very few forward/backward linear phase EQs on the market and thEQorange, with its wide, 80 bit double precision processing and optimized–for–fidelity algorithm, will bring a new sense of transparency to your work.
With all the features and functionality of Algorithmix’s beloved original LP PEQ Orange, the feature–packed thEQorange brings so much more. Use its powerful processing and double precision I/O for:
  • Mastering and remastering tasks on complex, high fidelity mixes
  • Equalizing of instrumental group stereo sub–mixes
  • Clarifying the midband and rescuing dense mixes
  • Addressing resonances and peaky instruments without tonal degradation
  • Removing unwanted ultrasonic content from HRA recordings
  • Identifying resonances with ease when sweeping, due to the low inherent ringing
  • Putting mixes with too much DC or a super fat kick on a diet
  • Tightening up loose or crowded mixes
All true linear phase EQs have similar specs. Dirac spikes and other artificial test signals will produce about the same results regardless of whose product you try. A solo chime or kick drum track is also not what thEQorange was designed for…It excels at equalizing an entire mix.
What not to use thEQorange for is tracking or mixing! thEQorange is a low channel count plug–in, designed for the master buss and mastering. Due to the insane complexity of the algorithm, thEQorange has a high CPU demand. It is not a “light weight”!
thEQorange fits in with all modern workflows:
  • Supports LPCM sample rates up to 384k for DSD and high–end postproduction
  • All standard formats: AU, VST 2 and 3, AAX
  • Compatible with macOS and Windows
  • Low fatigue visual design
  • Resizable user interface for every screen resolution

My Go To

Tischmeyer says: “The Algorithmix Orange was an essential part of my chain for more than 15 years. It was my ‘to go’ tool when I needed to remove annoying frequencies and resonances or when the midrange was simply cluttered by too many events with too much energy. The same applies to our thEQorange. The magic of thEQo is that I can remove frequencies without having the feel that I have applied a drastic EQ. I simply don’t hear the EQ. The result sounds natural, and suddenly the stereo image opens up — not as a side effect of the EQ but rather more as a result of creating space so that everything falls into the right place instead of fighting against each other. Furthermore, I use it as my preferred low cut to go. Yes, despite it is being a linear phase EQ. Most mastering engineers would not do that because of the fear of pre–ringing artifacts. For me, it is always a question of trade offs when it comes to the choice of a proper low cut in mastering. A minimal phase (IIR or Infinite Impulse Response) EQ comes with a high risk of destroying the master in the time domain due to its phase behavior. This can create a kind of transient smearing because different frequency components of the same transient event do not appear at the same time any longer (known as Group Delay). This could be a very tiny delay but enough to create an unnatural sense which is why I tend to avoid minimal phase EQs for low cutting. Also, a first order 6 dB per octave low cut is no alternative because it just does an inefficient job. On the other hand, a linear phase equalizer comes with the risk of smearing the transient with pre-ringing. However, with reasonable settings of the low cut, like a Q of 0.78 at 25 Hz, the ringing is so irrelevant and unnoticeable that I achieve a far tighter and apparently time correct result. This is why we say that thEQorange has no smearing effect on transients, if it is applied with real world, sensible settings so that pre-ringing is kept to a minimum.
In many cases, when I control too much low end in a mix, the kick suddenly goes from distracting low end artifacts to appearing more punchy and sometimes seeming to have more bass which is not logical but subjectively so since there’s less clutter. I can just explain it another way: It seems like more bass because the bass has a legitimate ‘pocket.’ It also translates better on the monitor system because it is delivered as a correct, time–aligned pulse together with the high frequency components.”

If One is Good & Two is Better…

People have asked us why we haven’t included alternative modes like minimal phase and all the other options you find in competing products. Our goal as plug-in designers is to create tools from the user prospective, offering just enough flexibility with a carefully chosen set of options so the user can focus on the job at hand. It would be easy to add dozens of additional options to the preferences window but why? As a mastering engineer, you need specialized tools which do a particular job in the fastest and best possible manner.
thEQorange is a perfect example of just such a tool. It offers everything you need to declutter a messed up mix, and we mastering engineers certainly receive such mixes more often as we would want. As an example, we didn’t include the irrelevant choice between different windowing options, like Blackman or Hamming, because it won’t improve your deliverable. Having those options available in a DSP library does not mean the end user needs to see them.
thEQorange was tuned by Dr.s Musialik and Hatje, who have already worked through an extensive refinement process. When asked about this, Musialik stated that “…the optimization and refinement of our algorithms was a very long, tedious and iterative procedure between research, development and feedback from experienced mastering engineers. Unfortunately, in high res audio, not everything is measurable or provable by numbers. This is especially true for the measurement of dynamic behavior and reactions to real–world, complex signals.”
Musialik emphasizes that “There is no ‘best’ audio tool for everybody.” His advice: Perform your own listening tests, then select which additions you want to include in your kit.

Learn More

This video from Friedemann provides an overview of thEQorange

Watch it directly on YouTube

Download — thEQorange User Manual

The user manual PDF includes mucho useful info, check it out…

Reviews & Testimonials

Thomas Meitz, Editing Department Head at Vienna Symphonic Library GmbH

“Zuerst muss mal gesagt werden, dass thEQorange wirklich einfach Spaß macht!
Ich habe bereits einige Projekte damit bearbeitet und es ist wirklich einfach zum richtigen Ergebnis zu kommen!
Einerseits weil der EQ so schön „nichtfärbt“, andererseits sind die Zusatzfeatures ausgezeichnete Hilfsmittel.
Die Bearbeitung im Bassbereich ent-mumpft grandios und ein High-Shelf im Differenzsignal macht schön breit ohne irgendwie scharf zu werden!
Nach anfänglicher Skepsis: Ich liebe das Spektrogramm!
Die Solofunktion der Gain-Änderungen finde ich super, muss damit aber noch warm werden.
Snap-Funktion bei Rechtsklick auf die Pianoroll ist sehr praktisch.
Sort-Funktion = Spitzenmäßig!
Ich finde das GUI super aufgeräumt, beschriftet wo notwendig und intuitiv!
Skalieren ist super und zeitgemäß – ich kenne allerdings kein Plugin das IMMER gleich gut aussieht – das geht wahrscheinlich nicht…

In Summe: Ich gratuliere zu einem hervorragenden EQ!

“First of all, it has to be said that thEQorange is really fun!
I've already done some projects on it and it's really easy to get the right results!
On the one hand, the EQ is nicely neutral and does not “color,” on the other, the additional features are excellent tools.
The editing in the bass range de-clutters terrific and a high-shelf on the difference signal makes beautiful wide without any kind of sharpness!
After initial skepticism: I love the spectrogram!
I think the solo feature of the monitor section with positive and negative gain changes is great, but I still need to get used to it.
Snap function on right-click on the piano roll is very convenient.
Sort function = Tops!
I think the GUI is super clean, labeled where necessary and intuitive!
Scaling is great and up to date - but I do not know a plug–in that ALWAYS looks the same - that probably will not work…

In summary: I congratulate you on an excellent EQ!

Andrea Zanini, CEO & Chief Mastering Engineer at Owl Mastering

“Some digital plug–ins deliver precision, while others deliver musicality. thEQorange is definitely a juicy tool, squeezing both qualities in a single, exquisite piece of audio engineering.”

Thom Wettstein, Mondstein Records

“I have tried thEQorange in every mastering. Sometimes it fits, sometimes not.
I like the features of re-ordering the bands and listening just to the cuts or boosts. It’s easy to find the sweet spot. I like the Interface a lot. It's comfortable to work with. The strength of this plug–in, in my opinion, is the de-masking of the mid frequencies. It’s very transparent.”

Patrik Schwitter (organ builder, musician, educator, award–winning mastering engineer)

“It just sounds fantastic or, to be more clear, it does not have any sound (i.e. colouration) at all! I'm totally convinced of this orange beauty. :) ”

Tomi Kuusisto, Audio Chef Mastering (EMI Finland, Warner Music)

“The search for the ultimate EQ is finally over. I have to say that you really nailed it with thEQorange!
It is more than an awesome tool for mastering as well as for mixing. I have tried all the mainstream pro plugin EQs out there but thEQorange is something unique; transparent and very musical…The show is not over until the thEQorange sings!”

Олег Ершов (Oleg “Yorshoff” Yershov, engineer & journalist)

“This thEQo is simply insane! I’m shocked how good it is…(my) overall impression is just WOW!”

Oleg released a video overview and review of thEQorange. His conclusion, “It amazes with the functionality and sound quality of its algorithms…Comparing thEQorange with other equalizers, using it for solving various problems during mixing and mastering, I continue to (think) this equalizer is really the king among digital equalizers.”
Watch it here: Отзыв Олега, на русском языке…

He also wrote a piece on thEQorange for the Russian edition of FutureMusic. In it, he states that, “Again, if the original PEQ Orange stood out from the competition mainly due to its technical characteristics (first of all, its (sound) quality)…Friedemann and his colleagues at MAAT were able to make thEQorange a user-friendly device, be it a home musician or a professional mastering engineer of world class - high demands and expectations…
Having spent enough time with thEQorange, I really enjoyed this (plug–in) - it works easily, quickly and with pleasure. Is it worth the money? I think that everyone should answer this question on their own but I, in turn, do not plan to abandon this plug-in and continue with great pleasure to use it in my mixes.

Read it here: Полный обзор PDF, на русском языке

Benoît Piccand, studio head & faculty lecturer in the Music Division of Bern University of the Arts

“After the first few days of experimenting with thEQorange: I am really thrilled; on the one hand, by the tonal results, but also by the interface: simple, extremely pragmatic and equipped with maximally useful functions. Unique and very beneficial!
I'm curious to see and hear what the other family members (blue and red?) have to offer.”


Praise for the original Algorithmix LinearPhase PEQ Orange

thEQorange is a modern restoration of the original Linear Phase PEQ Orange from Algorithmix. Thanks to improvements in technology since the PEQ Orange was released, our new version exceeds the already legendary fidelity of the original. Plus, we’ve added key new tech to the UX (User Experience) to make your time with thEQorange easier and more pleasurable.

Sakis Anastopoulos, Digisound Mastering

“I must tell you that I am absolutely ecstatic with the results that I have been achieving with the linear phase EQs…Both Red and Orange EQs have absolutely replaced every other EQ that I own and have given me the ability and freedom to perform challenging frequency adjustment tasks in every project that I master no matter how challenging or what genre it is…Their ability to resolve with accuracy, clarity and musicality, frequency ranges in complex music passages is astonishing, allowing the mastering engineer to focus on the project and forget the artifacts that are usually associated with this kind of processors.”

Stefan Lindstrom, Swedish Sound Reference AB

“Having the ($6k) hardware Weiss Linear Phase EQ1-MK2 as the reference, I've never expected to hear any other product, especially a software PlugIn, playing in the same league, but the LinearPhase PEQ Orange became to be an indispensable complement tool in our mastering suite.”

Bob Katz, Digital Domain

“…the Algorithmix Red and Orange Linear Phase equalizers are must haves.”

Alan Silverman, Arf! Digital

“…as the final touch-up EQ…the sound is fantastic!”

T-Dogg on our Dr. Christoph’s chops

“The real gurus in the field…Dr. Christoph Musialik, etc. have far surpassed these textbook algorithms…Simply put, genius–level R&D and know–how is priceless.” We concur and know that you will too!

Reviewers! Want to add your voiceover to the mix?

Head to our Contact page and give a shout…We’d love to hear what you think!


Interested?

thEQorange requires a 3-Series CmStick USB dongle. Our CmSticks offer portability, easy disaster recovery and reliabilty for your valuable purchase. Before you say, “Oh no, not another dongle!” consider this; your MAAT dongle investment includes a $50 voucher, which can be applied to your next purchase from our store. Learn more

Speeds & Feeds

Features, Specifications & Downloads

Downloads

• Download the user manual for thEQorange here

• If you own thEQorange, grab a cross–platform installer of the current build…

• If you want to listen to some thEQorange samples, please download this ZIP file (62 MB). It contains four samples, corrected for equal loudness. Besides an unprocessed original version, you will find a file with only thEQorange processing and no other changes. As a reference, you will also find a screenshot of thEQorange displaying all setup information along with a thEQo preset file if you already own our product.
Important! Please consider that the sample files were created from a mastering engineer’s perspective, where a number of specialized tools and EQs would be applied one after the other, as something like a jigsaw puzzle being fitted together.
A typical approach is to first remove resonances and clutter without degrading the audio quality, in this case utilizing thEQorange. Subsequently, other equally specialized tools would be applied downstream for additional subjective improvements. We would recommend thEQblue to fill in additional warmth, and employ thEQred for high frequencies correction and added “air.” In other words, these audio file examples address only the first step in a chain of tools, rather than an unmastered/mastered A/B example. These thEQorange examples are aimed at decluttering the mix to get the audio ready for subsequent treatment.

Features

  • Fully parametric linear phase EQ +
  • Free of group delay
  • Exclusive Contribution Control
  • Live spectrogram and spectrograph
  • AutoGain for effortless A/B comparisons
  • Variable resonant ƒ tunings for common Western scales
  • Inbuilt tone generator for quick spectral navigation

Supporting

  • AAX (Pro Tools 10.3.10 and newer), AU, VST 2, VST 3
  • Sample rates from 44.1 to 384 kHz
  • pluginval_logo  Verified by pluginval, passing with a score of 10 (the highest strictness level)

VST

VST PlugIn Interface Technology by Steinberg Media Technologies GmbH

License

  • Perpetual: One–Time Buyout
  • Subscription: Annual

Requirements

  • macOS 10.8 and newer
  • Windows 7 and newer, 32 & 64 bit

thEQorange

Perpetual License: $990
12 Month Subscription (Annual Renewal): $119
